Anritsu Spectrum Analyzer MS2663C 9 kHz to 8.1 GHz Spectrum
Analyzer
Description of Anritsu MS2663C
The MS2663C covers a frequency range of 9 kHz to 8.1 GHz. This
allows measurement of spurious frequencies of up to three times
greater than the frequency bands used worldwide for mobile
communications. The MS2663C has superior basic performance such as
high C/N ratio, low distortion, and high frequency/level accuracies
and are easy to operate. The MS2663C has a Measure function for
evaluation of radio equipment (frequency counter, C/N, adjacent
channel power, occupied frequency bandwidth, burst average power,
and template decision function), and enables the Two-screen display
and FM demodulation waveform display. The large selection of
options means that a wider range of applications can be handled at
reasonable cost.
Features:
- Frequency counter
- C/N
- Adjacent channel power
- Occupied frequency bandwidth
- Burst average power
- Noise power
- PASS/FAIL limit lines
List of Options
| 01 | Reference crystal oscillator |
| 02 | Narrow resolution bandwidth |
| 04 | High-speed time domain sweep |
| 06 | Trigger/gate circuit |
| 07 | AM/FM demodulator |
| 08 | Pre-amplifier |
| 10 | Centronics interface |
| 12 | QP detector |
| 14 | PTA parallel I/O |
| 15 | Sweep signal output |
| 20 | Tracking generator |
| Reference crystal oscillator | improves accuracy |
| Narrow resolution bandwidth | 30, 100, 300 Hz |
| High-speed time domain sweep | 1.25 μs/div |
| Trigger/gate circuit | Pre-trigger and post trigger available |
| AM/FM demodulator | Outputs to loudspeaker or earphone connector |
| Pre-amplifier | 100 kHz to 3 GHz, 20 dB |
| Centronics interface | GPIB cannot be installed simultaneously |
| QP detector | Requires Narrow resolution bandwidth option |
| PTA parallel I/O | Cannot be installed with the Centronics interface option |
| Sweep signal output | X, Z |
| DC coupled input | Requires Narrow resolution bandwidth option |
| Tracking generator | Built-in |
| Television monitor (Multi) | M-NTSC, B/G/H/I/D PAL |
| 75 W input | Cannot be installed with QP detector, DC coupled input, and
Tracking generator simultaneously |
| 75 W tracking generator | Cannot be installed with QP detector, DC coupled input, and
Tracking generator simultaneously |
