Used Fluke 5522A Multifunction Calibrator Multi-Product Test
Equipment
Product Description Of Fluke 5522A
The 5522A Multi-Product Calibrator addresses a wide calibration
workload and comes with internal and external protection features
that protect it against damage and make it easier to transport for
on-site or mobile calibration.
It is the ideal calibrator for metrology professionals who need to
perform resistance calibration, voltage calibration, current
calibration and more, and who want a transportable instrument that
offers them a high return on investment.
The 5522A is a voltage calibrator, a resistance calibrator, a
current calibrator and much more. It sources direct voltage and
current, alternating voltage and current with multiple waveforms
and harmonics, two simultaneous voltage outputs or voltage and
current to simulate dc and ac power with phase control, resistance,
capacitance, thermocouples and RTDs.
The 5522A can also measure thermocouple temperature, and pressure
using one of 29 Fluke 700 Series pressure modules. Two options add
the capability to calibrate oscilloscopes either 600 MHz or 1.1
GHz. And the 5520A-PQ Power Quality Option enables the 5522A to
calibrate power
quality instrumentation to the standards of the IEC and other
regulatory agencies.
The 5522A calibrator covers many of the electronic test tools you
use to keep your company up and running, including:
- Current clamps and clamp meters
- Thermocouples and RTDs
- Process calibrators
- Data loggers
- Strip and chart recorders
- Watt meters
- Power harmonics analyzers
- Panel meters
- Graphical multimeters
- Power quality analyzers (with option)
- Analog or digital handheld and bench oscilloscopes to 600 MHz or
1.1 GHz (with options)
Features:
- Calibrates a wide variety of electrical test equipment
- Robust protection circuits prevent costly damage from operator
error
- Resistance calibrator, voltage calibrator, current calibrator and
more
- Redesigned carrying handles make the 5522A easy to transport
- Rugged optional carrying case with built-in handles and wheels and
removable front/rear access doors for in-situ calibration in almost
any environment
- Remarkably affordable
List of Options:
1GHZ
| 1100 MHz / Oscilloscope Calibration Option |
6
| 600 MHz / Oscilloscope Calibration Option |
PQ
| Power Quality Option |
PQ/1GHz
| Multiproduct Calibrator with Power Quality and 1100 MHz
Oscilloscope Calibration Options |
PQ/6
| Multiproduct Calibrator with Power Quality and 600 MHz Oscilloscope
Calibration Options |
SC1100
| |
Technical Parameters:
Summary Specifications |
| Function & Range | |
| Direct volts | 0 to ± 1020 V |
| Direct Current | 0 to 20.5 A |
| Alternating volts | 1 mV to 1020 V
10 Hz to 500 kHz |
| Volt*Hertz | 1000 V@ 10 kHz/330 V@100 kHz |
| Alternating current | 29 μA to 20.5 A
10 Hz to 3s0 kHz |
| Waveforms | Sine, square, triangle, truncated sine |
| Resistance | 0 MΩ to 1100 MΩ |
| Capacitance | 220 pF to 110 mF |
| Power (phantom loads) | 20.9 kW |
| Phase control | 0.01° |
| Thermocouple (source and measure temperature) | B, C, E, J, K L N R, S, T, U
10 μV/°C |
| RTD (source temperature) | Pt 385-100 Ω, Pt 3926-100 Ω Pt 3916-100 Ω,
Pt 385-200 Ω, Pt 385-500 Ω, Pt385 1000 Ω,
PtNi 385-120 Ω, (Ni120), Cu 427 10 Ω |
| Interfaces | RS-232, IEEE 488 |
| Phase lock | Yes |
| Frequency uncertainty | <2.5 ppm |
| External frequency reference (10 MHz) | Yes |
| Calibration Documentation | 17025 accredited report of calibration included |
| Oscilloscope calibrator (optional) | Levelled sine wave from 5 mV to 5.5 Vpp max, frequencies 50 kHz to
600 kHz and 3.5 Vpp max to 1100 MHz; edge rise times of < 300ps,
multiple trigger functions, lowest dc, square wave and timing
uncertainty |
| Power calibrator (optional) | Composite harmonic, flicker simulation, sags and swells simulation
modes |
