| 2RL | Extended record length - 125M max, 25 M/Ch |
| 2SR | Double maximum real-time sample rate - 40/20/10 GS/s on 1/2/4ch |
| 3 | CALIBRATION SERVICE 3 YRS. PROVIDES TRACEABLE OR FUNCTIONAL
VERIFICATION EVENTS WHICHEVER ARE APPLICABLE TO THE PRODUCT. CALS
ARE AT TEKTRONIX RECOMMENDED INTERVAL DURING THE COVERAGE PERIOD.
CAL COVERAGE INCLUDES THE MANUFACTURERS CAL + 2 |
| 5 | CALIBRATION SERVICE 5 YRS. PROVIDES TRACEABLE OR FUNCTIONAL
VERIFICATION EVENTS WHICHEVER ARE APPLICABLE TO THE PRODUCT. CALS
ARE AT TEKTRONIX RECOMMENDED INTERVAL DURING THE COVERAGE PERIOD.
CAL COVERAGE INCLUDES THE MANUFACTURERS CAL + 4 |
| 5RL | Extended record length - 250M max, 50M/Ch |
| A0 | North America |
| A1 | Universal EURO |
| A10 | China |
| A11 | India |
| A12 | Brazil |
| A2 | United Kingdom |
| A3 | Australia |
| A5 | Switzerland |
| A6 | Japan |
| A99 | No Power Cord or AC Adapter |
| C3 | CALIBRATION SERVICE 3 YRS. PROVIDES TRACEABLE OR FUNCTIONAL
VERIFICATION EVENTS WHICHEVER ARE APPLICABLE TO THE PRODUCT. CALS
ARE AT TEKTRONIX RECOMMENDED INTERVAL DURING THE COVERAGE PERIOD.
CAL COVERAGE INCLUDES THE MANUFACTURERS CAL + 2 |
| C5 | CALIBRATION SERVICE 5 YRS. PROVIDES TRACEABLE OR FUNCTIONAL
VERIFICATION EVENTS WHICHEVER ARE APPLICABLE TO THE PRODUCT. CALS
ARE AT TEKTRONIX RECOMMENDED INTERVAL DURING THE COVERAGE PERIOD.
CAL COVERAGE INCLUDES THE MANUFACTURERS CAL + 4 |
| D1 | CALIBRATION DATA REPORT |
| D3 | CALIBRATION DATA REPORT 3 YEARS (WITH OPTION C3) |
| D5 | CALIBRATION DATA REPORT 5 YEARS (WITH OPTION C5) |
| DB | DPO Demonstration Board |
| DDRA | DDR Memory Bus Analysis (requires DJA) |
| DDU | Distributor Demonstration Unit |
| DJA | Jitter and Eye Analysis Tools - Advanced (DPOJET) |
| ET3 | Ethernet Compliance Testing |
| G3 | Three Year Gold Care Plan. Includes expedited repair of all product
failures including ESD and EOS, access to a loaner product during
repair or advanced exchange to reduce downtime, priority access to
Customer Support among others |
| G5 | Five Year Gold Care Plan. Includes expedited repair of all product
failures including ESD and EOS, access to a loaner product during
repair or advanced exchange to reduce downtime, priority access to
Customer Support among others |
| JA3 | Jitter and Timing Measurements - JIT 3 Advanced |
| L0 | English manual |
| L1 | French manual |
| L10 | Russian Manual |
| L3 | German manual |
| L5 | Japanese manual |
| L7 | Simple Chinese Manual |
| L8 | Standard Chinese Manual |
| L9 | Korean manual |
| L99 | NO MANUAL |
| LSA | Low-speed Automotive Serial Analysis bundle includes CAN/LIN
Trigger, Decode, and Analysis |
| LT | Waveform Limit Testing |
| MTM | Mask Testing, Includes Hardware Clock Recovery on DPO7254/7355 |
| PS1 | Power Solution Bundle: DPOPWR, P5205, TCP0030, TPA-BNC, 067-1686-XX
(Deskew Fixture) |
| PWR | Power Measurement and Analysis |
| R3 | REPAIR SERVICE 3 YEARS (INCLUDING WARRANTY) |
| R3DW | REPAIR SERVICE COVERAGE 3 YEARS (INCLUDES PRODUCT WARRANTY PERIOD);
3 YEAR PERIOD STARTS AT TIME OF CUSTOMER INSTRUMENT PURCHASE. |
| R5 | REPAIR SERVICE 5 YEARS (INCLUDING WARRANTY) |
| R5DW | REPAIR SERVICE COVERAGE 5 YEARS (INCLUDES PRODUCT WARRANTY PERIOD);
5 YEAR PERIOD STARTS AT TIME OF CUSTOMER INSTRUMENT PURCHASE. |
| SR-COMP | Computer Serial Triggering and Analysis (RS-232/422/485/UART) |
| SR-DPHY | MIPI D-PHY (DSI1 / CSI2) Serial Analysis |
| SR-EMBD | Embedded Serial Triggering and Analysis (I2C, SPI) |
| SR-USB | USB Serial Triggering and Analysis |
| SRCOMP | Computer Serial Triggering and Analysis (RS-232/422/485/UART) |
| SRCUST | Custom Serial Analysis Kit for Developers |
| SRDPHY | MIPI D-PHY (DSI1 / CSI2) Serial Analysis |
| SREMBD | Embedded Serial Triggering and Analysis (I2C, SPI) |
| SRUSB | USB Serial Triggering and Analysis |
| SSD | Additional Removable Disk - Solid State Drive (customer
installable) |
| SVE | SignalVu Essentials - Vector Signal Analysis Software for
Oscilloscopes |
| SVM | General Purpose Digital Modulation Analysis. Requires Opt. SVE |
| SVO | Flexible OFDM Analysis, Requires Opt. SVE |
| SVP | Advanced Signal Analysis (including pulse measurements), Requires
Opt. SVE |
| SVT | Settling Time, Frequency, and Phase. Requires Opt. SVE |
| USB | USB 2.0 Compliance Testing |
| VET | Visual Trigger and Search |
