5560A: The next generation high-performing calibrator supporting
the widest workload coverage
The 5560A Calibrator defines a new class of high-performance
multi-product calibrator, providing the broadest electrical
workload coverage and highest accuracy for calibrating the most
demanding modern workloads.
5550A: Optimized for your multimeter workload
The 5550A Performance Multi-Product Calibrator enhances the 5522A
with new calibration ranges optimized to better match your existing
digital multimeter workload in a modern, ruggedized instrument with
intuitive graphical interface.
5540A: Better performance for on-site or mobile calibration
The 5540A Multi-Product Calibrator extends the capabilities of the
5502A with better performance suited for on-site or mobile
calibration.
Product overview: Fluke 5550A and 5540A Multi-Product Calibrators
A new patented ultra-linear analog-to-digital design enables the
5550A and 5540A to achieve performance specifications that were not
possible in the 5522A and 5502A, allowing you to calibrate a more
accurate and demanding workload. Calibrate multimeters
significantly faster with improved settling time in both the 5550A
and 5540A. You’ll have less wait time and more time actually
performing the tests.
The 5550A and 5540A multi-product calibrators work with MET/CAL,
including hundreds of automated calibration procedures to
consistently and dramatically improve throughput. MET/CAL v10.6 and
later includes a Function Select Code (FSC) that enables you to add
the 5550A and 5540A seamlessly to your existing calibration
operations.
5550A Performance Multi-Product Calibrator for your multimeter
workload
The 5550A enhances the 5522A Multi-Product Calibrator with new
calibration ranges optimized to better match your existing digital
multimeter workload in a modern, ruggedized instrument with an
intuitive graphical interface. It calibrates the most popular
benchtop digital multimeters with improved test uncertainty ratios
(TURs), oscilloscopes to 1 GHz, and clamp meters to 1500 A with
continuous current output.
- 30 A continuous current output
- Improved test uncertainty ratios (TURs)
- Use with a 52120A amplifier to increase the current output to 6000
A for calibrating high-current components such as Rogowski coils
5540A Multi-Product Calibrator for on-site and mobile calibration
The 5540A extends the capabilities of the 5502A Multi-Product
Calibrator with better performance suited for on-site or mobile
calibration, covering many of the most demanding field
instrumentation workloads. It calibrates the most popular handheld
digital multimeters with increased test uncertainty ratios (TURs),
oscilloscopes to 600 MHz, and clamp meters to 1500 A with
continuous current output.
- 30 A continuous current output
- Range redesign enables you to calibrate your existing handheld
digital multimeters with greater confidence
- Use with a 52120A amplifier to increase the current output to 6000
A for calibrating high-current components such as Rogowski coils
Key features
- Intuitive calibration experience with 17.8 centimeter color touch
screen
- Better match your existing digital multimeter workload with
optimized ranging
- Easily calibrate meters that measure AC/DC voltage, resistance and
capacitance
- 30 A continuous current output extends AC/DC measurement ranges
| Function | Range |
| Direct volts | 0 V to ± 1020 V |
| Direct current | 0 to ± 30.2 A |
| Alternating volts | 1 mV to 1020 V
3 Hz to 500 kHz |
| Alternating current | 10 μA to 30.2 A
3 Hz to 30 kHz |
| Volt/hertz | 1000 V at 10 kHz/330 V at 100 kHz |
| Waveforms | Sine wave, triangle wave and
truncated sine wave |
| Resistance variable | 0 Ω to 1200 MΩ |
| Capacitance variable | 200 pF to 120 mF |
| Inductance variable | 12 uH to 12 H |
| Power (dual output – phantom loads) | 30.9 kW |
| Oscilloscope bandwidth | 2.1 GHz, 1.1 GHz, or 600 MHz |
| Phase lock | Yes |
| Phase control | 0.01° |
| Frequency uncertainty | <2.5 ppm |
| Temperature standard | <ITS-90, IPTS-68 |
Resistance temperature detectors
(RTDs) output | Pt100 385, Pt100 395, Pt100 3916, Pt200 385,
Pt500 385, Pt1000 385, Ni120, Cu10
Compensation: off, 2-wire, 4-wire |
| External frequency reference 10 MHz | Yes |
Thermocouples (source and measure)
External or internal CJR | B,C,E,J,K,L,N,R,S,U, BP and XK
10 μV/°C |
| Scope calibrator | SC600 – with levelled sine up to 600 MHz
SC1100 – with levelled sine up to 1100 MHz
SC2100 – with levelled sine up to 2100 MHz |
| Interfaces / Remote commands | USB 2.0, Etherne Telnet, RS-232 and GPIB |
| 52120A Amplifier current capability | Current capability up to 120 A
Current capability up to 360 A with three
52120As (parallel) |
Models Available for: Fluke 5560A, 5550A and 5540A Multi-Product
Calibrators:
5560A High-Performance Multi-Product Calibrator5560A/2GHigh-Performance Multi-Product Calibrator + 2.1 GHz Oscilloscope
Calibration Option
5560A/1GHigh-Performance Multi-Product Calibrator + 1.1 GHz Oscilloscope
Calibration Option
5560A/600MHigh-Performance Multi-Product Calibrator + 600 MHz Oscilloscope
Calibration Option
5550APerformance Multi-Product Calibrator
5550A/1G
Performance Multi-Product Calibrator + 1.1 GHz Oscilloscope
Calibration Option
5550A/600MPerformance Multi-Product Calibrator + 600 MHz Oscilloscope
Calibration Option
5540AMulti-Product Calibrator
5540A/600MMulti-Product Calibrator + 600 MHz Oscilloscope Calibration Option
