Agilent''s DSA90000A series oscilloscopes add Serial Data Analysis, EZJIT+, 50 M memory standard to the equivalent DSO90000A products.

The Infiniium DSO90000 series boasts industry-leading technology that allows for superior oscilloscope performance that goes beyond the specifications. Custom software to speed your measurement tasks can be fully integrated inside the oscilloscope application for seamless operation. Hardware acceleration aids measurement speeds and throughput. And our RF and probing experts have ensured that you get the most accurate measurements every time with less scope noise to interfere and probes that operate to the full bandwidth of the scope.

Superior Oscilloscope Signal Integrity
13 GHz bandwidth.
40 GSa/s on each of 4 analog channels
Standard 50 Mpts memory per channel, upgradeable to industry leading 1 Gpts
Includes Serial Data Analysis, and EZJIT+ software
Engineered for Unmatched Real-Time Measurement Accuracy
Industry''s lowest noise floor at 3.37 mV at 100mV/div
Deepest jitter analysis capability (PRBS^23) and most accurate real-time Tj and Rj characterization for data rates at 8.5 Gb/s and below
Hardware accelerated de-embedding allows easy compensation for probe, fixture, and channel effects. Get more details here.
Pass Today''s Demanding Compliance Tests More Quickly
Over 30 software applications for compliance, debugging and analysis including: SATA 6G, PCI EXPRESS® II, HDMI, Ethernet, DDR, etc. See the complete list at Compliance applications
Our industry experts in key standards organizations ensure that our tools include the right measurements every time
Predefined test suites and complete reports mean technicians can execute tests thus freeing valuable engineering resources.
Debug Your Toughest Designs with Confidence
New User Defined Application allows for rapid automation of any scope measurement. Find and share user defined applications at Agilent Discussion Forum.
Customize your Infiniium oscilloscope using User Defined Functions, User Defined Application, and My Infiniium for more efficient operation. Find and share customization examples at Agilent Discussion Forum.
MATLAB® software available directly from Agilent for making your own custom measurement and analysis routines, user-defined filters, or instrument applications. MATLAB software for Agilent oscilloscopes

The design concept Evaluate signal integrity. Validate compliance. Debug and analyze designs. When we developed the Infiniium 90000A Series, we took a close look at the key tasks that engineers of high-speed digital and RF designs perform. Then we created a series of scopes that could help you manage each of these tasks quickly and easily. We tapped the expertise we've acquired during 50+ years spent advancing scope technology. So you can finally work with an ultra-performance scope that keeps up with you and your leading-edge designs.

Infiniium multi-chip module isolates EMI. To enable our scopes to operate at high frequencies with minimal electromagnetic interference (EMI), we relied on our expertise in radio frequency (RF) technology. Instead of implementing each component of a digital circuit in a separate circuit block, we created a multi-chip module that uses a “Faraday Cage” to isolate EMI. The result? High-bandwidth scopes with the lowest noise floor in the industry.

InfiniiMax offers you the highest performance available for measuring differential and single-ended signals, with flexible connectivity solutions for today’s high-density ICs and circuit boards.
InfiniiMax probes have fully characterized performance for all of their various probe heads. This includes:
• Swept frequency response plot
• Common mode rejection versus
frequency plot
• Impedance versus frequency plot
• Time-domain probe loading plot
• Time-domain probe tracking plot

Offering the industry’s widest range of available compliance applications to provide fast setup for complete, automated compliance and margin testing and reporting, the Keysight DSA91304A scopes have become the go-to tool for test houses worldwide. The Keysight DSA91304A boasts an ever-expanding set of measurement applications for serial debugging and protocol viewing, jitter testing, advanced triggering, measurement customization, and rapid automation. Put the power of the scope to work for your unique debug and analysis challenges.
