R&S NRPxxS NRP33S NRP33SN NRP33SN-V three-path diode power
sensors
Description of NRPxxS NRP33S NRP33SN NRP33SN-V three-path diode
power sensors
The R&S®NRPxxS/SN power sensors use three separate diode paths,
each operated in the optimum detector range. As a result, the
average power can be determined with high accuracy independent of
the modulation type. Measurement results are hardly affected by
interfering signals or harmonics. The R&S®NRPxxS/SN power
sensors therefore behave in a way similar to thermal power sensors
but offer significantly higher speed. They provide up to 93 dB
dynamic range with an excellent lower measurement limit of –70 dBm.
Key features of NRPxxS NRP33S NRP33SN NRP33SN-V three-path diode power sensors
The most important features for accurate and uncomplicated power
measurements are top measurement accuracy and speed as well as
simple operation on a base unit or a computer. The NRP sensors
provide these characteristics in a comprehensive portfolio of LAN
and USB power sensors.
All NRP sensors are independent measuring instruments. Using a USB
adapter, you can directly connect them to a computer and operate
them via the R&S NRPV software.
Functions and performance features:
● Fully characterized power sensors
● Minimized measurement uncertainty
● Intelligent averaging function minimizes measurement time
● Versatile measurement functions
Additional features:
● USBTMC for easy system integration
● Built-in trigger I/O port
● Sensor status at a glance with status LED
● Detachable cables for flexible operation
Sensor tour of NRPxxS NRP33S NRP33SN NRP33SN-V three-path diode
power sensors
List of Available models
| NRP8S | 10 MHz-8GHz |
| NRP8SN | 10 MHz-8GHz, LAN interface |
| NRP18S | 10 MHz-18GHz |
| NRP18SN | 10 MHz-18GHz, LAN interface |
| NRP33S | 10 MHz-33GHz |
| NRP33SN | 10 MHz-33GHz, LAN interface |
| NRP40S | 50 MHz-40GHz |
| NRP40SN | 50 MHz-40GHz, LAN interface |
| NRP50S | 50 MHz-50GHz |
| NRP50SN | 50 MHz-50GHz, LAN interface |
| NRP67S | 50 MHz-67GHz |
| NRP67SN | 50 MHz-67GHz, LAN interface |
| NRP18S-10 | 10 MHz-18GHz |
| NRP18S-25 | 10 MHz-18GHz |
| NRP90S | 50 MHz-90GHz |
| NRP90S | 50 MHz-90GHz |
| NRP90SN | 50 MHz-90GHz, LAN interface |
| NRP33SV-V | 10 MHz-33GHz, LAN interface |
| NRP67SN-V | 50 MHz-67GHz, LAN interface |
| NRP-Z5 | USB sensor hub |
| DCV-1 | Documentation of calibration values |
| DCV-ZP | Printout of DCV |
| NRP-ZKU | USB-A interface cable, length: 0.75 m |
| NRP-ZKU | USB-A interface cable, length: 1.5 m |
| NRP-ZKU | USB-A interface cable, length: 3.0 m |
