Tested and calibrated Rohde and Schwarz FSU67 20Hz to 67GHz Spectrum Analyzer

Description of FSU67 Spectrum Analyzer

The R&S FSU67 is the first spectrum analyzer with a direct frequency range to 67 GHz and fundamental mixing. It allows measurements to 67 GHz without using cumbersome setups with external mixers.

Simplified test set-ups with just one connection from 20 Hz to 67 GHz
Full span sweep of 67 GHz
Unambiguous frequency indication without the image response and multiple responses known from external harmonic mixers
Wider level range with a much higher allowable reference level than with harmonic mixers
Good level accuracy to 67 GHz
Low noise floor: -152 dBm (1 Hz) at 2 GHz, -130 dBm (1 Hz) at 65 GHz
Wide range of resolution bandwidth: 1 Hz to 50 MHz
Versatile filter characteristics: Gaussian, channel filters, FFT, 6-dB EMI filters
Full range of detectors including RMS, quasipeak
Comprehensive power measurement functions (CP, ACP, time domain power)
NRP power heads can be connected directly (Option FS-K9 and NRP-Z6 required)
Harmonic distortion and spurious emissions measurement function
High display linearity < 0.1 dB
Phase noise and noise figure application firmware
External generator control for use of an external microwave generator as tracking generator for scalar network measurements

Frequency

R&S® FSU3: DC coupled 20 Hz to 3.6 GHz AC coupled 1 MHz to 3.6 GHz

R&S® FSU8: DC coupled 20 Hz to 8 GHz AC coupled 1 MHz to 8 GHz

R&S® FSU26: DC coupled 20 Hz to 26.5 GHz AC coupled 10 MHz to 26.5 GHz

R&S® FSU43: DC coupled 20 Hz to 43 GHz

R&S® FSU46: DC coupled 20 Hz to 46 GHz

R&S® FSU50: DC coupled 20 Hz to 50 GHz Frequency range

R&S® FSU67: DC coupled 20 Hz to 67 GHz Frequency resolution 0.01 Hz

The Rohde & Schwarz R&S FSU67 Spectrum Analyzer surpasses the proven excellent RF data of the R&S FSE and R&S FSIQ series of Spectrum Analyzers. Measurements calling for an extremely wide dynamic range are simpler, faster and more reliable – in development, quality management and production environments. The R&S FSU67 can rightly be called the new reference in spectrum analysis, with an unprecedented dynamic range:

TOI >20 dBm, typ. +25 dBm
1 dB compression (0 dB RF attenuation): +13 dBm
Displayed average noise level: –158 dBm (1 Hz bandwidth)
77 dB ACLR typ. for 3GPP, 84 dB typ. with noise correction
HSOI 55 dBm typ.
Phase noise: –160 dBc/Hz typ. at 10 MHz carrier offset

These characteristics make it easy to find small spurious signals even in the presence of strong carriers (e.g. at a base station).

For 3GPP adjacent-channel power measurements, a figure of 84 dB ACLR allows good adjacent-channel power (ACP) ratios to be verified and demonstrated very simply and with high accuracy. Build your node B better than others, and prove it.

The high harmonic second-order intercept point means optimum dynamic range for multichannel cable TV measurements.

The R&S FSU series of spectrum analyzers launched with the most abundant functionality available on the spectrum analyzer market. All major functions come straight away in the basic unit and include:

Highly selective digital filters from 10 Hz to 100 kHz
Fast FFT filters from 1 Hz to 30 kHz
Channel filters from 100 Hz to 5 MHz
RRC filters
1 Hz to 50 MHz resolution bandwidth
QP detector and EMI bandwidths 200 Hz, 9 kHz, 120 kHz
2.5 ms sweep time in frequency domain
1 µs sweep time in time domain
Number of measurement points/trace selectable between 155 and 10001
Time-selective spectrum analysis with gating function
GPIB interface, IEEE 488.2
RS-232-C serial interface, 9-pin SUB-D connector
VGA output, 15-pin SUB-D
PC-compatible screenshots on diskette or hard disk
Up to 20 measurements/s in manual mode
Up to 30 measurements/s on GPIB interface
SCPI-compatible GPIB command set
R&S FSE R&S FSIQ compatible GPIB command set
Fast ACP measurement in time domain
Statistical signal analysis with CCDF function
RMS detector of 100 dB dynamic range
Transducer factor for correcting antenna or cable frequency responses
2-year calibration cycle
External reference from 1 MHz to 20 MHz in 1 Hz steps
GGSM/EDGE modulation measurements (with option R&S FS-K5)

List of Options

B12	Output attenuator for tracking generator for FSU, FSQ
B18	Removable Hard Disk (not retrofittable)
B19	Second Hard Disk for FSU-B18 (for FSU-B18,variant 1303.0400.02)
B20	Extended environment specification. Random vibr. 1.9G RMS, 0-55°C (not retrofittable)
B21	LO/ZF connections for external mixers (for FSQ26, FSQ40,FSU26, FSU43, FSU46, FSU50)
B24	Preamplifier 30dB, 100 kHz to 50GHz (for FSMR26/43/50, FSQ26/40, FSU26/43/46/50;
B25	Electronic attenuator 0 to 30 dB, Preamplifier 20 dB, 10MHz - 3.6 GHz for FSU, FSQ
B27	FM output, 10 MHz bandwidth
B4	OCXO 10 MHz aging/year: 0.35*10E-7 for FSU, FSQ, FSMR
B5	Output for low phase noise 640MHz reference signal for FSU3, FSU8, FSQ3 und FSQ8
B73	Vector signal analysis for FSU demodulation bandwidth 8 MHz (FSU), broadband demodulation hardware included
B9	Tracking generator for FSU and FSQ, 100 kHz - 3.6 GHz
C3	THREE YRS OF DEPOT FACTORY STANDARD CALIBRATION BASED ON THE R&S RECOMMENDED CALIBRATION INTERVAL - INCLUDES TEST DATA. THE FIRST CALIBRATION IS INCLUDED WITH PRODUCT DELIVERY WITH 2 ADDITIONAL DEPOT CALIBRATION(S).
C5	THREE YRS OF DEPOT FACTORY STANDARD CALIBRATION BASED ON THE R&S RECOMMENDED CALIBRATION INTERVAL - INCLUDES TEST DATA. THE FIRST CALIBRATION IS INCLUDED WITH PRODUCT DELIVERY WITH 2 ADDITIONAL DEPOT CALIBRATION(S).
DCV-2	Documentation of calibration values
DCV-ZP	Printout of DCV (additional, in combination with DCV-Option only)
DKD	FSU67 DKD (ISO17025) calibration incl. ISO 9000 calibration (order only with device)
FS-K10	GSM/EDGE/EDGE Evolution Measurement Appl (for FSG/FSQ/FSU)
FS-K15	VOR/ILS measurements for FSMR
FS-K30	Application firmware for noise figure and gain measurements for FSMR, FSP, FSQ, FSU
FS-K40	Application firmware for phase noise measurements for FSMR, FSP, FSQ, FSU
FS-K5	Application firmware GSM/EDGE tests for FSP, FSU, FSQ
FS-K5U	Upgrade of FS-K5 to FS-K10, GSM/EDGE/EDGE Evolution Measurement Appl (for FSG, FSQ, FSU)
FS-K7	FM demodulator, allows measurement of FM specific parameters (for FMU, FSP, FSU)
FS-K72	Application firmware 3GPP-FDD BTS transmitter test for FSMR, FSP, FSU, FSQ
FS-K73	Application firmware 3GPP-FDD UE transmitter test for FSMR, FSP, FSU, FSQ
FS-K73+	3GPP HSPA+ UE transmitter test, application firmware (for FSMR, FSP, FSQ, FSU, FSUP,
FS-K74	3GPP HSDPA base station test application firmware for FSMR, FSU, FSP, FSQ
FS-K74+	3GPP HSPA plus, base station test. Application firmware (for FSP, FSQ, FSU, FSG;
FS-K76	3GPP TD-SCDMA base station test; application firmware for FSMR, FSP, FSQ, FSU
FS-K77	3GPP TD-SCDMA mobile station test; application firmware for FSMR, FSP, FSQ, FSU
FS-K8	Application firmware for Bluetooth measurement on FSP, FSU and FSQ
FS-K82	CDMA2000/1xEV-DV base station test application firmware for FSMR, FSP, FSU, FSQ
FS-K83	CDMA2000/1xEV-DV mobile station application firmware for FSMR, FSP, FSQ, FSU
FS-K84	1xEV-DO base station test application firmware for FSMR, FSU, FSP, FSQ
FS-K85	1xEV-DO mobile station test application firmware for FSMR, FSP, FSQ, FSU
FS-K9	Measurements with NRP power sensors NRP-Z11/Z21/Z22/Z23/Z24/Z51/Z55/Z91 requires NRP-Z3 or NRP-Z4
FSP-B10	External generator control for retrofit of FSP, FSU, FSQ, ESPI, ESCI
FSP-B28	Trigger port for FSP,FSQ,FSU; for indication of trigger conditions
